- 119 -
Replacing Consumables and Maintenance Units
4
4. Maintenance
Replacing the Belt Unit
Life Span of Belt Unit
When the “Belt Unit Near Life” message
appears on the display screen, prepare a
replacement belt unit. You can keep printing
approximately 1000 pages until the next
message appears.
When the “Change Belt Unit” message
appears, replace the belt unit.
The life expectancy of the belt unit is
approximately 80,000 pages for A4 simplex
printing (three pages per job).
Note
● The actual number of pages you can print with the belt
unit depends on how you use it.
Note
● Though opening and closing the top cover may extend
the life of the belt unit somewhat, you should replace it
soon after the “Change Belt Unit” is displayed to prevent
malfunction.
● If you replace the belt unit, use it until the end of its
useable life. If you remove the belt unit and install and
use another one before its usable life has expired, the use
life will not be correctly displayed.
● When the <ENTER> button > [Admin Setup] >
[System Setup] > [Near Life Status] is set to
[Disable], the [Belt Unit Near Life] message does not
appear.
Procedure for Replacement
Note
● The image drum (the green tube) is very delicate. Handle
it carefully.
● Do not expose the image drum to direct sunlight or very
bright interior light (approximately more than 1500 lux).
Even under the normal interior light, do not leave it for
more than 5 minutes.
1 Prepare a replacement belt unit.
2 Turn off your printer by pressing the
power switch.
Reference
● “Turning Off the Power” P.22
3 Insert your nger into the recess on
the right side of the printer and pull the
front cover open lever (1) to open the
front cover (2) forward.
1
2
4 Press the top cover open button (3) and
open the top cover (4).
CAUTION
Possible to get
burned.
● The fuser unit is extremely hot. Do not touch
it.
3
4
5 Take all the four image drums out of a
printer, and then place them on a at
surface.
To Next Page
