Replacing Consumables and Maintenance Units
4
4. Maintenance
5 Remove the image drum (6) from the
printer in the direction of the arrow and
place the image drum on a at surface.
6
6 Turn the right blue lever (7) of the toner
cartridge forward while pressing the top
of the toner cartridge to unlock.
7
7 Lift the toner cartridge (8) from the
right side, and remove it from the image
drum.
Possible to get
burned.
● Do not throw a used image drum and toner
cartridge in the re. They may explode, and
the toner inside may y off and cause getting
burned.
8
➊
➋
8 Remove the protective sheets.
Place a new image drum (9) on a at
surface.
9
9 Remove the toner cover (10).
10
10 Insert the toner cartridge (8) taken
out in step 7 to the image drum (9) by
aligning its left side indentation (11)
with the protrusion (12) on the image
drum, and then x the right side rmly
into place.
8
12
9
11
➋
➊
