- 125 -
Cleaning
4
4. Maintenance
2 Release the tab (3) of the paper feed
roller cover by pressing the right arm (4)
inward while lifting up the MP tray (1)
lightly.
1
4
3
3 Also press the left arm (4) inward while
lifting up the MP tray (1) lightly to
release the tab (3) of the paper feed
roller cover.
1
4
3
4 Open the paper set cover (5) until
touching the printer.
5
5 Wipe the two paper feed rollers (6) with
a wet cloth that has been wrung out
well.
6
6 Open the separation roller cover (7)
forward while pressing the center part of
the MP tray.
Wipe the two separation roller (8) with a
wet cloth that has been wrung out well.
7
8
7 Close the separation roller cover (7).
7
8 Lower the paper set cover (5).
5
To Next Page
