Oki Data CONFIDENTIAL
44043511TH Rev.2
10 /
Figure 1-2
1.2 Printer Composition
The internal part of the printer consists of the following parts.
• Digital Photo Processor
• Paper Travel Path
• Control Unit (CU and PU)
• Operation Panel
• Power Source (High Voltage Area/Low Voltage Area)
Figure 1-2 illustrates the printer composition.
