Oki MC363DN Configuration Guide

Advanced network settings > 62
34. On the Filter Action Wizard, click Next.
35. On the Filter Action Name screen, enter a Name and a Description and then click
Next.
36. On the Filter Action General Options screen, make sure that Negotiate security
is selected and then click Next.
37. On the Communicating with computers that do not support IPsec screen,
make sure that Do not allow unsecured communication. is selected and then
click Next.
38. On the IP Traffic Security screen, select Custom and then click Settings.
39. On the Custom Security Method Settings window, configure the settings and
then click OK.
40. On the IP Traffic Security screen, click Next.
41. Select Edit properties and then click Finish.
42. On the filter action properties window, select Use session key perfect forward
secrecy (PFS) if you want to enable Key PFS.
43. Select Accept unsecured communication, but always respond using IPsec if
you perform IPSec communication by the IPv6 global address.
44. Click OK.
45. Select the new filter action and then click Next.
46. On the Authentication Method screen, select the value you want and then click
Next.
47. Click Finish.
48. On the IP security policy properties window, click OK.
49. On the Local Security Policy window, select the new IP security policy.
50. From the
Action me
nu,
select Assign.
51. Make sure that Policy Assigned for the new IP security policy is displayed as Yes.
52. Click X on the Local Security Policy screen.
NOTE
Select the same values specified in the configuration for “Phase2 Proposal” in
“Configuring your machine” on page 60.

Oki MC363DN Specifications

General

Duplex printing	Yes
Print technology	LED
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Print speed (color, normal quality, A4/US Letter)	26 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Time to first copy (black, normal)	12 s
Time to first copy (color, normal)	14 s
Copy speed (black, normal quality, A4)	30 cpm
Copy speed (color, normal quality, A4)	26 cpm
Scan to	CIFS, E-mail, FTP, HTTP, PC, USB
Scan drivers	ICA, TWAIN, WIA
Scanner type	-
Scan speed (black)	30 inch/min
Image formats supported	JPG, MMR, RAW
Document formats supported	PDF
Fax memory	8000 pages
Modem speed	33.6 Kbit/s
Fax transmission speed	2 sec/page
Fax speed dialing (max numbers)	300
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	45000 pages per month
Recommended duty cycle	0 - 5000 pages per month
Number of print cartridges	4
Page description languages	Epson FX, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PDF 1.7, PostScript 3, SIDM
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	880 sheets
Total number of input trays	1
Maximum number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	50 sheets
Envelopes sizes	9, 10, C5, DL, Monarch
Photo paper sizes	10x15, 12.5x17.5 cm
Custom media width	64 - 216 mm
Custom media length	90 - 356 mm
Paper tray media weight	64 - 176 g/m²
Non-ISO print media sizes	16K, Executive (184 x 267mm), Folio (media size), Index card, Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Photo paper sizes (imperial)	4x6, 5x7 \
Multi-purpose tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	64 - 220 g/m²
Auto Document Feeder (ADF) media weight	60 - 105 g/m²
Display	LCD
Product color	Black, White
Display resolution	320 x 128 pixels
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Standard interfaces	Ethernet, RJ-11, USB 2.0
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1170 W
Power consumption (off)	0.5 W
Power consumption (sleep)	1.5 W
Power consumption (PowerSave)	20 W
Power consumption (average operating)	570 W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Storage temperature (T-T)	0 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	509 mm
Width	427 mm
Height	444 mm
