Oki MC780 series User Manual

- 17 -
Name and Function of Each Part
1
2
4
5
6
3
Image Drum Cartridge
(C: Cyan (Blue))
Image Drum Cartridge
(M:Magenta) (Red))
Image Drum Cartridge
(Y:Yellow (Yellow))
Image Drum Cartridge
(K:Black (Black))
Paper Remaining Indicator
Paper Size Dial
Toner Cartridge
(Y:Yellow (Yellow))
Toner Cartridge
(C:Cyan (Blue))
Fuser Unit
Toner Cartridge
(K:Black (Black))
Toner Cartridge
(M:Magenta) (Red))
USB Port
Vent
Power Switch
Power Connector
Interface Part
Duplex
Printing Unit
Faceup
Stacker
Ofine Stapler
(when installing
the ofine stapler)
USB Port
Vent
Power Switch
Power Connector
Interface Part
Duplex
Printing Unit
Faceup
Stacker
Inline
Stapler
<Interface Part>
ACC
TEL Connector
USB Interface Connector
LINE Connector
Network Interface Connector
(1000/100/10BASE)
LINE
TEL
HANDSET
LINE
COIN

Oki MC780 series Specifications

General

Brand	Oki
Model	MC780 series
Category	All in One Printer
Language	English
