Oldham MX 32 User Manual

6 – Wiring and Electrical Connections
31
16-Logic Input Module
Figure 30: 16-logic input module connections.
If this module is the last on the line, do not forget to set the
switch marked EOL resistor/resistance FDL to ON.
8-Analog Input Module
Figure 31: Connection of the 8 analog input modules (with 4-20mA detector)
Figure 32: connection of the 8 analog input module (with Wheatstone Bridge detector)
If this module is the last of the line, do not forget to set the
jumper marked EOL Resistor to Closed position.
To next module
To MX 32
or previous module
Supervised contact
Supervised contacts
To next module
To MX 32
or previous module
Wheatstone bridge type
detector
To next module
To MX 32
or previous module
