32
MX 32v2
User Manual
4 Analog Output Module
Figure 33: 4-analog output module connections.
If this module is the last of the line, do not forget to set the switch
marked EOL Resistor/FDL resistance to the ON position.
Positioned contact
Positioned contacts
To the next module
To MX 32
or the previous module
Output
4-20 mA n°1
Output
4-20 mA n°2
Output
4-20 mA n°4
Output
4-20 mA n°3
