5 Digital Modules
17
Chapter 5 │Digital Modules
This chapter presents the digital modules that may be installed on the MX 32
lines.
The details of module connection are given on page 27.
Digital modules are configured via COM 32 configuration
software.
Addressable Digital Modules
Up to 5 modules can be used with the single line version and up to 10
modules can be used with the 2 line models. The MX 32 in bridge version is
not compatible with any modules (see Table 1:). The following table lists the
available modules:
Type of module
Illustration
Page
4 Output Relay Module with 2 additional logic inputs
20
8 Output Relay Module with 2 additional logic inputs
20
8 Analog Input Module
23
16 Logic Input Module
22
4 Analog Output Module with 2 additional logic inputs
25
Table 4: Addressable digital modules
