Oldham MX 32 User Manual

54
MX 32v2
User Manual
8-Analog Input Module
Function
Function
4-20mA detector or Wheatstone bridge
connections
Capacity
1 to 8 independent inputs
Terminals
■ Screw terminals. Can accept 2.5 mm² (14AWG)
wire
■ Removable terminal without powering the line
down
Consumption
53 mA max (detector excluded)
Assembly
DIN rail mounted
Dimensions
125 x 165 x 60 mm
4-Analog Output Module
Function
Function
Generation of 1 to 4 analog values
Capacity
■ 4 4-20mA discrete opto-isolated outputs
(recopy detector, minimum, maximum, or
average of a detector group)
■ Resistance of maximum load 500 
Logic inputs
2 additional logic inputs (dry contacts)
Connections
■ Screw terminals. Can accept 2.5 mm² (14AWG)
wire
■ Removable terminal without powering the line
down
Terminals
■ < 5 mA with the 4 lines at stop
■ < 36 mA for an activated line
■ < 130 mA for the 4 activated lines
Assembly
DIN rail mounted
Dimensions
125 x 165 x 60 mm
