Oldham MX 32 User Manual

7 – Menus
43
Message
Significance
module absent).
MODUL
Configuration or module address error.
TEMP+
Internal temperature of the MX 32 higher than maximum tolerated value.
TEMP-
Internal temperature of the MX 32 lower than maximum tolerated value.
LINE 1
Incident on line 1 (short-circuit).
LINE 2
Incident on line 2 (short-circuit).
CAL O
Calibration defect (zero shifted).
CAL S
Calibration defect (used cell).
CAL F
Calibration defect (cell oversensitive).
CAL D
Calibration defect (measurement unstable).
Table 15: Material incidents file messages
6. System troubles records
This displays the events relative to MX 32 operation (power failure/fluctuation,
On/Off, etc.).
Previous page, Next page, and Last page allow access to the corresponding
pages of the file; each page can display a maximum of 8 lines.
Message
Significance
ON
MX 32 on live voltage
OFF
MX 32 off voltage
Self-testing failure
Failure of internal tests
Other messages
Contact Post-Sales Service
Table 16: System incidents file messages
3. Slave info
These data enable maintenance technicians to visualize the communication
framework between MX 32 and the digital modules.
4. Controller info
These data allow technicians to visualize different counters such as number of
resets on low voltage input, error system, configuration, etc.
