Oldham MX 32 - Page 8

4
MX 32v2
User Manual
Figure 2: Example of an MX 32 configuration using different analog and digital detectors
as well as digital modules
MX 32
Configuring PC with the
COM 32 application
Digital detectors
2 logic
inputs
Analog recorders
Four 4-20mA Analog
Output Module
8 Relay Output Module
Logic Input Module
4 Relay Output
Module
16 logic
inputs
Analog inputs
External
power supply
USB
link
8 Analog Input Module
