Oldham MX43 User Manual

4 – The MX43 Central Unit 15
Chapter 4 І The MX43 Central Unit
Overview of the Unit
External view
080
Rep. Function Rep. Function
A. Monochromatic, backlit graphic
display
H. Failure/maintenance indicator
B. Zone 1 status indicator J. Contextual soft keys
C. Zone 2 status indicator K. Alarm release key
D. Integrated siren (option) L. Free identification of zones
E. Integrated flash (optional) M. Strip for locating zones
F. Lock N. Handle
G. Start/Stop indicator
Figure 8: External view of the wall-mounted and rack-mounted versions.
