16-Logic Input Module
Function
Function
Logic input monitoring.
Capacity:
1 to 16 logic inputs (dry contacts).
Connections:
■ Screwed terminals.
■ Connector detachable without cutting the line
■ Tightening torque: 0.5-0.6 Nm.
■ Cable: 2.5 mm² maximum.
Consumption:
2 mA in normal operation.
Assembly:
Snap-on on DIN rail.
Dimensions:
125 x 165 x 60 mm.
8-Analog Input Module
Function
Function:
4-20mA detector or Wheatstone bridge
connections.
Capacity:
1 to 8 independent inputs.
Connections:
■ Screwed terminals.
■ Connector detachable without cutting the line.
■ Tightening torque: 0.5-0.6 Nm.
■ Cable: 2.5 mm² maximum.
Consumption:
53 mA max (detector excluded).
Operating temperature:
8 bridges
- 30°C (8 bridges up to 1 km).
- 40°C (8 bridges up to 500 m).
4 bridges
- 45°C (4 bridges up to 1 km).
- 50°C (4 bridges up to 500 m).
Assembly:
Snap-on on DIN rail or mounted on the inside of
MX43.
Dimensions:
125 x 165 x 60 mm.
4-Analog Output Module
Function
Function:
Generation of 1 to 4 analog values.
Capacity:
■ 4 independent opto-isolated outputs 4-20mA
(recopy detector, minimum, maximum, or
average of a detector group).
■ Resistance of maximum load 500 .
Logic inputs:
2 additional logic inputs (dry contacts).
Connections:
■ Screwed terminals.
■ Connector detachable without cutting the line
