Oldham MX43 User Manual

6 – Electrical Connections 41
118
Figure 38: 4 Analog output module connections.
If this module is the last of the line, do not forget to set the jumper
switch marked EOL Resistor/FDL resistance to the ON position.
To the next module
To MX43
or the previous module
Output
4-20 mA n°1
Output
4-20 mA no. 2
Output
4-20 mA no. 4
Output
4-20 mA n°3
