44 | Page Oliver Machinery 10044 Planer
Key
Part Number
Descriptions
Specifications
QTY
1
924830-000
Handle Assembly
1
1.1
090354-148
Elevation Arm
1
1.2
250260-615
Handwheel
1
1.3
250262-615
Handwheel Cap
1
1.4
251421-675
Ring with Depth Marking
1
1.5
250662-615
Pin
1
1.6
360302-901
Pan Head Phillips Screw with Lock Washer
1
2
000302-103
Pan Head Phillips Screw
M4*0.7P*10
3
4
049103-104
Star Screw
M6*1.0P*12
1
5
000802-101
Bottom head socket screw
M8*1.25P*16
4
6
251399-615
Upper Cover
1
7
251400-615
Vent Lid
1
8
200111-615
Foam
Black-2mm
1
10
923507-000
T Wrench
1
11
001601-101
Pan Head Phillips Screw with Washer
M4*0.7P*8/4*10*0.8t
11
12
029301-101
Star Screw with Lock Washer
M5*0.8P*10/5.1*7.9
2
13
924827-000
Dust Plate Assembly w/Foam
1
14
014303-000
Belt
135J-9
1
15
008036-200
Hex Nut
M16*1.5P(23B*8H)
1
16
110010-000
Cutterhead Pulley
1
17
010107-000
R Ring
RTW-47
1
18
030208-001
Bearing
6204-2NSE
1
19
924888-000
Byrd Shelix Cutterhead Assembly
1
040704-000
Torx Screwdriver
T-25
1
038201-103
Torx Screw
10-32
36
A-BYRD 10
Inserts Sold in Packs of 10
36
23
012003-002
Key
5*5*10
1
25
280035-901
Spring
3
26
130088-000
Bushing
4
27
001602-704
Pan Head Phillips Screw
M5*0.8P*20
4
28
660010-000
Washer
4
29
170737-902
Bracket (Right)
2
30
000303-104
Pan Head Phillips Screw
M5*0.8P*12
10
31
340098-000
Rubber Roller
2
32
280036-901
Spring
1
33
016204-000
Chain
#410*26P
2
34
170736-902
Bracket (Left)
2
35
380257-901
Sprocket
1
36
150004-000
Sprocket
2
37
010006-000
S Ring
STW-15
2
38
000302-102
Pan Head Phillips Screw
M4*0.7P*8
3
