Page #33 background image
Index
Part No. Description Specification
QTY
Old P/N
0
923360-000 Tool Box 1 923184-000
8 000103-102 CAP Screw M6*1.0P*10 2 HA020404
20 230322-000 Nut for Bits S45C 1
85 006001-022 Flat Washer 6.3*13*1t 2 HE010300
109 172936-000 Machine Positioning Plate Galvanized 2
124 041306-002 Polybag 190*130(Open)*0.15t 1 HR051500
125 660179-000 Brush 125*54*40 1
126 040203-000 Open Wrench (double sided) 11*13 1 HQ020800
127 040205-000 Open Wrench (double sided) 14*17 1 HQ021100
128 040401-000 Screwdriver
1*75
1
129 660175-000 Tool Box
Plastic(Clear)175(L)*110(W)*95(H)
1
1
029402-101
Hex. Screw w/Spring and Flat Washer
M6*1.0P*16/6.1*12.3/6.3*13*1.0t
26
2 310247-909 Z Axis Rail (Left) 6061 1 FH010063
3 310253-909 Z Axis Rail (Right) 6061 1 FH010069
4 310270-909 Z Axis Nut Bracket 6463 1 FH010103
5 310269-909 Z Axis Positioning Plate 6463 1 FH010102
7 922494-000 Block WJ200UM-01-10 8
8 000103-102 CAP Screw M6*1.0P*10 46 HA020404
9 006501-100 Serrate Washer 4.3*8.5(BW-4) 7 HE040600
10 000302-702 Hex. Head Screw M4*0.7P*8 31 HA040403
11 000102-103 CAP Screw M5*0.8P*10 5
12 923358-000 Spindle Assembly 15000rpm 150W/110V/60Hz 1
.1 923238-000 Bit Spindle Assembly 15000rpm 150W/110V/60Hz 1
.1.1 922883-000
Brushless Motor and Spindle Assembly
1
499010-000 DC Brushless Motor TECO 1
360930-901 Spindle SCM435 1
.1.2 490770-000 Spindle Drive (110V) 1
.2 490761-000 Power Supply NES-150(110V) 1
13 923029-000 Bit Chuck Assembly 1
.1 047101-212 ER Chuck ER11(Ø6.5) 1
.2 381044-000 Conical Bit
Carbide(1.6x25.4x6.35sx60Lx11°xR0.8)
1
.3
381020-000 End Mill Bit Carbide(3.17*12*6.35s*60L)
1
14 000103-106 CAP Screw M6*1.0P*16 18 HA020408
15 173124-902
Z Axis Block SPCC 1 FH010121
16 000303-703 Round Head Screw M5*0.8P*10 26 HA040604
17 033708-000 Ball Bearing 6002-2NKE 1
18 172752-902 Plate SPHC 1
1013 Parts List
