Oliver M-1013 User Manual

7
Specifications
1013 intelliCarve
Item
Description
Spec
1
Travel
1.1
X axis
331mm(13")
1.2
Y axis
457mm(18")
1.3
Z axis
76mm(3")
2
Tool
2.1
shank OD
¼”
2.1
cutter
conical R1/32” (0.8mm) / end mill D1/8” (3.2mm)
2.2
Cut depth
Max 25.4mm(1")
3
Spindle
3.1
speed
15000rpm
3.2
motor
150w DC brushless
4
Transmission
4.1
X/Z lead screw diameter
16mm(0.63”)
4.2
X/Z rail material
IGUS WX-01-10
4.3
Y axis
Rack & pinion
6
Feed Speed
6.1
speed
3M/min(118in/min)
6.2
position accuracy
0.1mm (0.004”)
6.2
reposition accuracy
±0.1mm (0.004”)
7
Step motor
7.1
Max torque
17.3 kg-cm(15lb-in)
7.2
step angle
1.8 °
7.3
voltage(Max.)
24V/Phase
7.4
current(Max.)
2.8 A/Phase
8
Sensor
8.1
no of sensors(X/Y/Z)
2/2/2
9
Control Interface
9.1
LCD
(46x30)mm
9.4
keypad
10 keys
9.6
interface
USB Port × 1

Oliver M-1013 Specifications

General

Brand	Oliver
Model	M-1013
Category	Power Tool
Language	English
