upper case mode.
EDIT/SHIFT key, (14,f)
This is a toggle key used to activate the numeric
keypad, and
the PG UP, PG ON, HOME, and END functions.
Keyboard connector (IO,A)
This connects the keyboard to the system.
Back panel/interfaces
2-8
Socket for DC power connection (15,f)
Systeas with hard disk: ON/OFF switch for hard disk
(15,E)
Parallel interface (15,A)
This is used to connect a printer (parallel).
Serial interface (15,e)
This is used to connect equipment requiring a serial
interface.
Interface for 5.25" disk drive (15,8)
This is used to connect the optional 5.25" disk drive.
Air outlets (15,D): You should keep these outlets free
from paper etc. on systems with hard disk.
MI5 PLUS INSTALLATION AND OPERATIONS GUIDE
