11
EN
Preparations for shooting
Basic guide
Preparing the battery
2
3
1
1
2
3
BLS-1 Lithium ion
battery
AC wall outlet
BCS-1 Lithium
ion charger
AC cable
Battery lock
It is recommended to set aside a backup battery for prolonged shooting in case the battery
in use drains.
1 Charging the battery
3 Close the battery compartment cover and slide the battery
compartment lock in the direction of E
Press the battery lock to
unlock the battery.
Battery
compartment lock
Battery compartment
cover
Direction indicating
mark
Unloading the
battery
2 Loading the battery
Charging indicator
Amber light: Charging in progress
Blue light: Charging complete
(Charging time: Up to approximately 3
hours 30 minutes).
Amber blinking: Charging error
W
W
• Be sure to turn off the camera when you open or close the battery compartment cover.
• When using the camera, be sure to close the battery compartment cover.
