Olympus E-600 - Attaching a Lens to the Camera

12
EN
Attaching a lens to the camera
2
1
1
2
3
4
3
2
1
Body cap
Lens cap
Alignment mark (Red)
Lens release button
1 Remove the body cap from the camera
and the rear cap from the lens
2 Attach a lens to the camera
• Make sure the ON/OFF switch
is set to OFF.
• Do not press the lens release
button.
3 Remove the lens cap
(
3, 4)
Removing the lens from the
camera
While pressing the lens release button
(1), rotate the lens in the direction of
the arrow (2).
• Align the lens attachment mark (red)
on the camera with the alignment
mark (red) on the lens, then insert the
lens into the camera’s body (1).
• Rotate the lens in the direction
indicated by the arrow until you hear it
click (2).
Rear cap
Lens attachment
mark (Red)
1
2
