140
EN
12
Information
Product type
Product type : Single-lens reflex digital camera with interchangeable lens system
Lens : Zuiko Digital, Four Thirds System Lens
Lens mount : Four Thirds mount
Equivalent focal length on
a 35 mm film camera : Approx. twice the focal length of the lens
Image pickup device
Product type : 4/3" Live MOS sensor
No. of total pixels : Approx. 13,060,000 pixels
No. of effective pixels : Approx. 12,300,000 pixels
Screen size : 17.3 mm (H) × 13.0 mm (V) (0.7" × 0.5")
Aspect ratio : 1.33 (4:3)
Viewfinder
Product type : Eye-level single-lens reflex viewfinder
Field of view : Approx. 95% (for field of view on recorded images)
Viewfinder magnification : Approx. 0.96× (-1 m
-1
, 50 mm lens, infinity)
Eye point : Approx. 18 mm (0.7") (-1 m
-1
)
Diopter adjustment range : -3.0 - +1.0 m
-1
Optical path fraction : Quick return half mirror
Depth of field : When PREVIEW registered with the < button
Focusing screen : Fixed
Eyecup : Interchangeable
Live view
: Uses Live MOS sensor for shooting, adjustable
: Field of view of 100%
LCD monitor
Product type : 2.7" TFT color LCD
Total no. of pixels : Approx. 230,000 dots
Shutter
Product type : Computerized focal-plane shutter
Shutter : 1/4000 - 60 sec., Bulb shooting
Auto focus
Product type : TTL phase-contrast detection system/Imager contrast detection
system
Focusing points : 7 points/11 points: with [IMAGER AF]
AF luminance range : EV -1 - EV 19 (ISO 100 equivalent, at room temperature 20 °C
(68 °F), TTL phase-contrast detection system)
Selection of focusing point : Auto, Optional
AF illuminator : The built-in flash provides light.
Specifications
Camera specifications
