Chapter 3 Installation and Connection of the Workstation
57
OLYMPUS CAPSULE ENDOSCOPE SYSTEM
6. Connect the recorder unit cradle to the workstation.
Connect the recorder unit cradle cable to the recorder unit cradle’s cable
connector, then connect the other end of the recorder unit cradle cable to
the USB connector on the workstation.
7. Confirm that the workstation, the LCD monitor, and the printer are turned
OFF.
8. Connect the power cables for all equipment to wall power outlets.
The conversion cable is equipped with two connectors on the
monitor end, but only one of them can be used. Connect the
monitor cable to the connector labeled “1”.
