SPECIFICATIONS / IX Series
II .
DSU
II .
7-2
Page
7-2 IX Series
Item Specifications
Lens-barrel magnification 1x
Number of views Visual observation side: FN22mm (In reflected illumination, peripheral
light intensity may be insufficient if objection lens is of 20x or less)
Camera observation side: FN11mm
Shutter Knob at front side turret cover.
Field iris diaphragm Field iris diaphragm built-in type (with centering function)
Aperture opening: Knob push-pull method
Centering: With use of the Allen screwdriver
Disk Belt-drive system supported by spindle
DC motor
Electrically driven IN/OUT system (with hand switch)
Filter Electric filter wheel
Electric 6-hole turret system 1: Empty hole
2: ND25
3: ND12
4: ND6
5: ND3
6: ND1.5
Front turret Manual 6-hole turret system
1-hole fixed mirror accessory (Reference mirror)
Mirror unit turret
Rear turret Electric 6-hole turret system
1-hole fixed mirror accessory (Reference mirror)
Stand Height adjustable
2 units provided.
Observation methods Camera observation
1) Incident-light fluorescent disk confocal
2) Incident-light fluorescent
3) Transmitting
Visual observation
1) Incident-light fluorescent
2) Incident-light fluorescent + Transmitting differential interference
3) Incident-light fluorescent + phase contrast
4) Transmitting
Dimensions of main unit
408mm(W)×386mm(D) ×221mm(H)
Weight 10kg
This device complies with the requirements of both directive 89/336/EEC concerning electromagnetic
compatibility and directive 73/23/EEC concerning low voltage. The CE marking indicates compliance with
the above directives.
