Olympus OEV261H - Chapter 6 Submenu Operations; INPUT CONFIG

Chapter 5 Screen Menu and Operation of Front Panel
33
High definition LCD monitor OEV261H
PRESET J
INPUT CONFIG
Video/Y/C AUTO
RGB/YP
B
P
R
RGB-VIDEO
SELECT SYNC AUTO
COMP.
RGB SQUARE
HD15 SQUARE
DVI-D1 DVI-COMP.
DVI-D2 DVI-VIDEO
VIDEO CONFIG
BACKLIGHT 50
COLOR TEMP. D65
COLOR MODE of each
input terminal
VIDEO 8-A
Y/C 8-A
RGB/YP
B
P
R
8-A
HD15 6-A
SDI1 8-A
SDI2 8-A
DVI-D1 6-A
DVI-D2 8-A
SYSTEM CONFIG
MENU POSITION
STATUS DISPLAY 3SEC OFF
POWER ON SETUP LAST
POWER SAVE MODE OFF
LANGUAGE ENGLISH
LOGO ON
FUNCTION
FUNCTION1 PORT A GAMMA SELECT
FUNCTION2 PORT B GAMMA SELECT
FUNCTION DISPLAY ON2
WINDOW CONFIG
PIP
PORT A DISPLAY
MODE
5:4
PORT B DISPLAY
MODE
SQUARE
DISPLAY POSITION
POP
PORT A DISPLAY
MODE
5:4
PORT B DISPLAY
MODE
SQUARE
DISPLAY POSITION MODE1
DISPLAY PATTERN PORT A
SQUARE PATTERN MODE1
REMOTE CONFIG
GPI CONTROL DISABLE
GPI1 PORT A INPUT SDI1
GPI2
PORT A INPUT RGB/YP
B
P
R
GPI3
PORT A INPUT VIDEO
GPI4 PORT A INPUT Y/C
GPI5 UNDEF
GPI6 UNDEF
GPI7 UNDEF
GPI8 UNDEF
CONTROL
CONTROL LOCK ON
FRONT LOCK MENU
INPUT
PORT A SDI1
PORT B SDI2
