Chapter 5 Screen Menu and Operation of Front Panel
High definition LCD monitor OEV261H
• When the right and left images trade places, the input PORT and signal
display follow suit.
• Status display of an enlarged view appears at top left of the
screen during PIP operation.
• Select one of the following display periods.
− CONTINUE
− 3 SEC OFF
− OFF
However, FLIP status is always displayed.
Table 5.1 shows the signal format and display on the monitor.
• “UNSUPPOTRT SIGNAL” appears if an unsupported signal
is input. It may also indicate that the format selected in the
“INPUT CONFIG” menu does not match the input signal.
• “NO SIGNAL” appears if no signal is input.
• “UNSUPPORT SIGNAL” and “NO SIGNAL” may not be
properly displayed.
:
Upside-down image
:
Reversed image
