Chapter 6 Submenu Operations
High definition LCD monitor OEV261H
GAMMA
SELECT
Sets the incline of the gamma curve.
• ENDOSCOPE (default value)
•1.8
•1.95
•2.0
•2.2
•2.4
•2.6
•PACS
SCAN SIZE HD
SD
Magnifies the single screen display and the large screen in PIP mode.
When COMP. input is selected, the set value is — (line). This cannot be selected, nor any other
selection can be made.
When GPI is enabled and an item is assigned, the item appears gray to indicate that selection is
disabled and the set GPI value appears.
SCAN SIZE SD
OFF Normal display
MODE1 Magnifies SD signal image to horizontal panel size (1920 pixels)
MODE2 Magnifies SD signal image to vertical panel size (1200 pixels)
SCAN SIZE HD
OFF Normal display
MODE3 Magnifies HD signal image to vertical panel size (1200 pixels)
MODE4 Magnifies special area 1 (1422 × 1064) of an HD signal to horizontal panel size
(1920 pixels).
MODE5 Magnifies special area 1 (1422 × 1064) of an HD signal to vertical panel size
(1200 lines).
MODE6 Magnifies special area 2 (1280 × 1008) of an HD signal to horizontal panel size
(1920 pixels).
MODE7 Magnifies special area 2 (1280 × 1008) of an HD signal to vertical panel size
(1200 lines).
SD Aspect ratio is fixed at 4:3.
SD only input terminals display SD items only (MODE1 and 2).
* HD signal: MODE3 to 7 described above enable only 1080i (60 Hz/59.94 Hz/50 Hz) or 1080p
(60 Hz/59.94 Hz/50 Hz) HD signals, other HD signals are impossible.
See page 61 for a description of a scan size.
Submenu Description
Normal screen PIP screen
target screen target screen
