27
4.3.5 Configuration (continued)
G) Remote Access
Remote IP Address: iServer can establish a connection to a remote device (e.g. an
iLD Remote Display with an Ethernet iServer embedded board) with this IP.
Remote Port: (default 2000) the remote port number for the connection.
Ports 1000 (used for HTTPget, refer to Section 4.5), 2002, 2003, and 2004 are
reserved for internal use.
Remote Access:** Remote Access can be enabled and disabled. If enabled, the
iServer can send its data to a remote node on the same network (the “Remote IP
address” and “Remote Port” must be entered).
*TCP/UDP: when UDP mode is selected, Remote Access should be disabled
and Remote IP and Port are the UDP remote listening IP and Port. If the
Remote IP is set to 255.255.255.255, the UDP packet becomes a
broadcasting packet which will allow any device listening to the Remote port
to receive the packet.
**If Remote Access is enabled, Terminal Server is automatically disabled.
H) Update
This button will save and update all changes made on the Configuration page.
Clicking on the “Update” button will also refresh the Configuration page and will give
you the latest Clock Time.
I) Start Recording
Click on this button to configure the Recording Settings.
Once the button is clicked the following Warning Message will appear.
Once a new Recording Starts, the existing data on the Flash Memory Card will
be entirely erased. You may want to download the existing data using iFlash
software (see Section 4.3.3) before starting the recording.
Once you click OK (on the above Warning Message) you will be prompted with the
following window:
Click on Continue Recording to
access the Recording Settings.
OK
Cancel
WARNING! New Recording Will Erase Existing Data. Download Data or Replace Flash.
Start Recording?
http://192.168.1.200
Address
http://192.168.1.200
Continue Recording
To Next Page
