4.3.6 Sensor Parameters
• In the first column of Configuration page (Figure 4.11), click on No. 1 to view and
modify the Sensor Parameters page for Temperature.
Figure 4.15 Sensor Parameters
Below are some definitions of terms used in the Sensor Parameters page.
Sensor Name: shows on the Configuration and the Read Sensor page.
Remote Display Format
: Remote display format is for Terminal Server continuous mode.
H_00.00% in humidity setting, displays H_ and 00.00% is the humidity value displayed.
Example: if the humidity is 30.00, then H_30.00% will be seen in the remote display. If no
format is specified (blank), there is no reading sent out. If temperature is 76.25 and 00.0F
is used in temperature setting, the remote site will show 76.2F.
This format setup is originally based on iLD Remote Display, which has four or six LEDs.
For six LEDs, T_00.00F format, and for four LEDs, 00.0F formats are appropriate.
Remote End Char: The default value is 0D (Hex
representation of <CR>). This means that the iServer
sends <CR> after each temperature, humidity, and
dewpoint value. This will be done either in Continuous or
Command mode. This is how the data will appear on the
host with 0D assigned:
T_75.70F
H_37.90%
D_44.90F
If the end character for instance is 20 (Hex representation
of space), the data will then appear as:
T_75.70F H_37.90% D_44.90F
If nothing is set for the “Remote End Char” field, the
iServer will then forward the data to the LAN with no
characters followed.
Offset: SInce the sensing probe is solid state electronics, there is no need for calibration. If
it’s determined that the readings are slightly off, the user can manually assign numerical
values to adjust the readings for temperature, humidity and dewpoint. For temperature
offset, the unit must be in degree C. The Offset can be changed while recording is on.
SENSOR PARAMETERS
Device No. 1
Sensor Name:
Main Menu
http://192.168.1.200
Sensor Parameters
Update Reset
Temperature
Remote End Char 0x:
0D
Remote Display Format:
T_00.00F
Offset:
( C
)
002.0
Cancel
32
T_75.70F
H_37.90%
D_44.90F
T_75.70F
H_37.90%
D_44.90F
T_75.70F
H_38.00%
D_44.90F
T_75.70F
H_37.90%
D_44.90F
Tera Term - 206.29.25.27 VT
File Edit Setup Control Window Help
Figure 4.16
Remote End Char
You may
type any
ASCII
characters in the
first two boxes,
but you must
delete the leading
spaces.
