Connectors and Interfaces
23
Pin Signal
1- Voltage_N
2- Voltage 3
3- Voltage 2
4- Voltage 1
1+ Current 1
2+ Current_N
3+ Current 3
4+ Current 2
Table 1 Assignment
Notice: For a left-hand rotating field Voltage_2 / Voltage_3 and
Current_2 / Current_3 are to be exchanged.
Manufacturer designation of plug for Generator Combination socket
Description SPEAKON LINE 8-pole
Article number NL8FC
Manufacturer Neutrik
Table 2 Manufacturer designation
Suppliers for plug for Generator Combination socket
USA Neutrik USA Inc., 195-S3 Lehigh Avenue, Lakewood,
NJ 08701-4527
Tel.: +1 (0)908 901 94 88, Fax: +1 (0)908 901 96 08
South Africa Eltron (Pty.) Ltd., P.O. Box 44598, Linden,
Johannesburg 2104,
Tel.: +27 (0)11 787 03 55, Fax: +27 (0)11 787 96 27
D Hermann Adam GMBH & CO KG
Felix -Wankel-Str. 1, 85221 Dachau,
Tel.: +49 (0)8131 2808-0 or
NCV GmbH,
Erzbischof Buchberger Allee 14, 93051 Regensburg,
Tel.: +49 (0)941 98041, FAX: +49 (0)941 999772
Table 3 Suppliers
ļ If you want to order from OMICRON, refer to section 7.2 "Ordering Notes ā.
