Omicron CMC 156 User Manual

Technical Data
31
5 Technical Data
The following data refer to a CMC 156 test set with standard design, without
external amplifiers.
 For test sets with the EP option (Extended Precision), technical data
regarding the power amplifiers are different from the corresponding data of
standard devices: therefore, these data can be found separately in chapter 6,
"Technical Data EP Option".
• Guaranteed values:
- In general:
Valid for 1 year from factory calibration, within 23 °C ± 5 °C
(73 °F ± 10 °F) at nominal value and a warm-up time of > 25 min.
- Guaranteed values of generator outputs:
Valid in the frequency range 10 – 100 Hz.
• Accuracy specifications:
Valid in the frequency range DC – 100 Hz.
5.1 Mains Supply
Mains supply
Connector Plug acc. to IEC320
Voltage, 1-phase
Nominal voltage
Permissible range
110 to 240 Vac
99V to 264 Vac
Mains fuse T6.3 AH 250 V
Power consumption < 600 VA
Frequency
Nominal frequency
Permissible range
50 / 60 Hz
47 to 63 Hz
Table 10 Supply data
