Test Set CMC 156

Socket Function

Pin 1 Counter input 1

Pin 2 Counter input 2

Pin 3 Reserved

Pin 4 GND connected with GNDA (Gen. Out 7-12)

Pin 5 Binary output 11

Pin 6 Binary output 12

Pin 7 Binary output 13

Pin 8 Binary output 14

Pin 9-16 Reserved

Housing Shield connection

Table 8 Assignment

Manufacturer designation of plug for "Gen. out 7-12" and

"ext. Interface"

For Gen. out 7-12:

Plug with 2 guide cams and pull relief

FGB.2B.316.CLAD 72Z

For ext. Interface:

Plug with 1 guide cam and pull relief

FGG.2B.316.CLAD 72Z

Bend protection spout black GMA.2B.070 DN

Table 9 Manufacturer designation

 If you want to order from OMICRON, refer to section 7.2"Ordering Notes “.
