5.3.3 Measuring Inputs
1 Direct current measuring input
Measuring range 0 to ± 20 mA
max. input current
1
600 mA
Accuracy typ. error 0.01 % guaranteed error < 0.05 %
Connection 4 mm banana sockets
or measuring comb. socket.
Isolation Electrically connected to the current and voltage
power outputs.
Table 21 Direct current measuring input
1 Direct voltage measuring input
Measuring range 0 to ± 10 V
max. input voltage
1
±11 V
max. input current
1
± 90 mA
Accuracy typ. error < 0.01 % guaranteed error < 0.05 %
Connection 4 mm banana sockets or measuring comb. socket.
Isolation Electrically connected to the current and voltage
power outputs.
Table 22 Direct voltage measuring input
1
Exceeding this value may lead to destruction in the device.
