Technical Data
45
5.6 Safety
Safety standards and certificates complied with
European standards EN 61010-1:1993
EN 60950 +A1:1993-05
International standards IEC 1010-1
CAN/CSA-C22.2 No 1010.1-92
Certificates
UL/CSA certified up to test set serial
number
Pxnnnx.
(Example: a test set with serial
number
ND224C is UL/SCA-certified,
a test set with the serial number
QB111D not).
Table 27 Safety standards and certificates complied with
5.7 Mechanical Data
Dimensions and weight
Weight 9.8 kg (22.46 lbs)
Dimensions W x H x D (without handle) 343 × 145 × 268 mm
(13.5"
× 5.7" × 10.6")
Table 28 Dimensions and weight
