4.1.1 Generator Combination Socket for
VOLTAGE OUTPUT, CURRENT OUTPUT
The combination socket CURRENT OUTPUT / VOLTAGE OUTPUT serves for
easy connection of the test object to the CMC 156. All signals of the
connection sections CURRENT OUTPUT and VOLTAGE OUTPUT are
brought out at this connector.
Figure 7 Plug for Generator Combination socket (view onto cable
connection side)
WARNING:
The connections on this socket are dangerous voltage
contacts when the test set is in its ON state; for this reason,
this socket may not be used without full knowledge of the
safety instructions found at the beginning of this manual.
