Technical Data EP Option
55
6.1.3 Output Power with EP option
The output power accuracy is defined only for the system CMC 156 with EP
option.
Output power accuracy
Accuracy
1
(VA) 0.05 % typical; 0.1 % guaranteed
Temperature drift 0.005 % / ° C max.
Table 33 Output power accuracy
Limitations for obtaining an accuracy of 0.1% on output power
Output current ranges
Range 12.5 A
Range 1.25 A
1.25 to 12.5 A
0.1 to 1.25 A
Permissible load and current
Range 12.5 A
Range 1.25 A
0 to 0.5
Ω and 6 VA max.
at cos
ϕ from 0.5 to 1
0 to 1
Ω and 1 VA max.
at cos
ϕ from 0.5 to 1
Permissible load and voltage max. 10 VA
Output voltage range 50 to 125 VAC
Frequency range 50/60 Hz
Table 34 Limitations for obtaining an accuracy of 0.1 % on output power
1
Valid under the conditions stated in Table "Conditions for output power measurement".
