Omicron CMC 156 User Manual

Technical Data EP Option
49
6.1.1 Current Outputs CURRENT OUTPUT 1-3
3 current outputs
1
range 12.5A
Output currents
3-phase AC (L-N)
1-phase AC (L-N)
in parallel
1-phase DC (L-N)
3
× 0 to 12,5 A
1
× 0 to 12, 5A
1
× 0 to 27 A at >45 Hz
1
× 0 to 21 A at <45 Hz
1
× 0 to ±12,5 A
Power
2
3-phase AC (L-N)
1-phase AC (L-L)
3
1-phase AC (L-N)
4
1-phase DC (L-N)
typ. 3
× 43 VA
typ. 1
× 86 VA
typ. 1
× 65 VA
typ. 1
× 62 W
guar. 3
× 40 VA
guar. 1
× 75 VA
guar. 1
× 74 VA
guar. 1
× 59 W
Resolution < 500 µA
Accuracy
5
typical error
< 0.015 % rd.
+ 0.005 % of rg.
guaranteed error
< 0.04 % rd.
+ 0.01 % of rg.
Harmonic distortion
6
typ. 0.025 % guar. < 0.05 %
Short-circuit protection Unlimited against N and from L to L.
Open-circuit protection Open outputs (idling) allowed.
Connection 4 mm banana sockets or amplifier
combination socket.
Isolation Reinforced isolation to mains and to all SELV
interfaces.
Table 30 Current outputs, range 12.5 A (EP option)
1
Data for 3-phase systems are valid under symm. conditions (0 °, 120 °, 240 °).
2
For higher current or output power demands connection of an external amplifier is possible (e.g.,
CMA current amplifier). The power data refers to an output current of 12.5 A
eff
or 12.5 A
DC
.
3
Single-phase model (operation with two phases in phase opposition):
two currents in series, additional adapter SPA1 or SPA156 recommended.
4
3 phases (3 x 9 A) in parallel for in-phase operation.
5
rd. = reading; rg. = range, whereat n % of rg. means: n % of upper range value (12.5 A).
6
Values at 50/60 Hz, 20 kHz measuring band width, nominal value and nominal load.
