Connectors and Interfaces
25
Pin Signal Cable color code Description
1 I7 wh Binary input 7
2 NC bn Not connected
3 NC gn Not connected
4 NC ye Not connected
5 I10 gy Binary input 10
6 I9 pk Binary input 9
7 I2 bu Binary input 2
8 I3 rd Binary input 3
9 GND_BI1 bk Binary GND 1
10 GND_BI2 vt Binary GND 2
11 I5 gy/pk Binary input 5
12 I6 rd/bu Binary input 6
13 I8 wh/gn Binary input 8
14 IDC*_IN bn/gn DC current input
15 NC wh/ye Not connected
16 NC ye/bn Not connected
17 I1 wh/gy Binary input 1
18 I4 gy/bn Binary input 4
19 GND_A wh/pk Analog GND
20 UDC_IN pk/bn DC voltage input
The shield is not connected within the CMC 156 and has therefore to be
connected within the signal source.
Table 4 Assignment Measurement Combination Socket
