Appendix
59
Most important specifications of the CMA 156:
Output currents
6-phase AC 6 x 0 to 25 A
3-phase AC
1
3 x 0 to 50 A
DC 1 x 0 to
± 25 A
Power
6-phase AC 6 x 70 VA at 7.5 A
3-phase AC
1
3 x 140 VA at 15 A
1-phase AC (L-L)
2
1 x 140 VA at 7.5 A
1-phase AC (L-L)
3
1 x 280 VA at 7.5 A
DC (L-N) 1 x 140 W at 10.5 A
Weight 15.6 kg (34.4 lbs)
Dimensions without handle
W x H x D 450 x 145 x 390 mm (17.7"
× 5.7" × 15.4")
Additional information about the CMA 156 can be found in the CMA 156
manual.
1
By connecting the two amplifier groups in parallel.
2
Single-phase model: two current phases in series.
3
By connecting four amplifier phases in series.
