8 - 3
8 Errors and Remedies
DriveProgramming User’s Manual (I622-E1)
8-1 Troubleshooting
8
8-1-2 DriveProgramming Operation on Error
Reset
The DriveProgramming operation on error reset varies with the reset input method and the setting for
the Reset Selection (CA-72). The following table shows the operation for each case.
To restart the DriveProgramming, set the Input Terminal Selection (CA-01 to CA-11) to 28 (RS (Reset))
and turn ON the corresponding input terminal.
*1. To restart the program, set the DriveProgramming Function Selection to 00 (Disabled) first, and then change
it to 02 (Always). Also, you can restart it by turning ON the PRG terminal again, if UE-02 = 01.
8-1-2 DriveProgramming Operation on Error Reset
Operation
Program status
Trip
status
Reset with control terminal
C102 = 00 or 01 C102 = 02 or 03
DriveProgramming operation During run Normal status Restart Keep run
During trip Restart Restart
During stop Normal status Restart
Keep stop
*1
During trip Restart Restart
Inverter's reset operation Normal status Reset Disabled
During trip Reset Reset
To Next Page
