3 - 15
3 Operation Procedure for DriveProgramming
DriveProgramming User’s Manual (I622-E1)
3-3 Program Structure
3
3-3-6 Task Operation on Trip
Basically, even if the inverter detects a trip during the DriveProgramming operation, the operation is
continued. However, if any of E043 to E045 trips related to the DriveProgramming is detected, the oper-
ation is stopped.
Or, with the “on trip goto” command, the program can jump to other process after a trip occurred.
For details on the trips E043 to E045, refer to Section 8 Errors and Remedies.
3-3-6 Task Operation on Trip
With/without
“on trip goto”
Error status
User trip
E050 to E059
DriveProgramming
related trip E043 to E045
Other trips
Without Operation is continued. Program is stopped. Operation is continued.
With After the “on trip goto”
command is executed, the
program jumps to the
specified label and the
operation is continued.
Program is stopped. After the “on trip goto”
command is executed, the
program jumps to the
specified label and the
operation is continued.
To Next Page
