B7A
B7A
91
Installation
Internal Circuits and Terminal Arrangement
Screw Terminal Models
B7A-T10S1
(Input,
Active Low)
Transmission
line
SIG
12 to 24 VDC
SW
+
SW
SW
Note: A
sensor with two-wire output
cannot be connected.
Internal circuit
SIG
SIG
IN0
A0
IN1
A1
IN2
A2
IN3
A3
IN4
A4
IN5
A5
IN6
A6
IN7
A7
IN8
A8
IN9
A9
B2
B1
B0
(–)
(+)
+
B3
B4
B5
B6
B7
B8
B9
Brown
(red)
Blue
(black)
Black
(white)
12 to 24 VDC
Push-button switchLimit switchPhotoelectric sensor
Three-wire proximity
sensor with built-in
amplifier (with NPN
output)
Ajj
Bjj
Ajj
Bjj
Ajj
Bjj
