B7A
B7A
92
B7A-T10S3
(Input, Active Low for
NPN 3-wire Sensor)
SIG
+
–
Transmission
line
12 to 24 VDC
SW
SW
Brown (red)
Proximity
switch
(NPN
output)
Black (white)
Blue (black)
Internal circuit
SIG
SIG
IN0
A0
IN1
A1
IN2
A2
IN3
A3
IN4
A4
IN5
A5
IN6
A6
IN7
A7
IN8
A8
IN9
A9
+
B2
–
B1
+
B0
(–)
–
(+)
+
–
B3
+
B4
–
B5
+
B6
–
B7
+
B8
–
B9
12 to 24 VDC
Black
(white)
Brown
(red)
Blue
(black)
Push-button
switch
Limit switch
Photoelectric sensor
Three-wire proximity sensor with
built-in amplifier (with NPN output)
Note: 1. A sensor with two-wire output
cannot
be connected.
2. The wire colors have been
changed in accordance with the
revision of the Japanese Indus-
trial Standards for photoelectric
sensors and proximity sensors.
The colors in parentheses refer
to
the old colors.
3. Do not short-circuit the SIG termi -
nal with the positive power supply
terminal, negative power supply
terminal, or a Bjj terminal,
otherwise the internal elements
of the B7A will be damaged and
no
transmission will be possible.
Ajj
Bjj
Ajj
Bjj
Ajj
Bjj
B7A-R10SC01
(Output, NPN Open
Collector)
SIG
SIG
OUT0
A0
OUT1
A1
OUT2
A2
OUT3
A3
OUT4
A4
OUT5
A5
OUT6
A6
OUT7
A7
OUT8
A8
OUT9
A9
+
B2
+
B1
+
B0
(–)
–
(+)
+
+
B3
+
B4
+
B5
+
B6
+
B7
+
B8
+
B9
ERROR
ERR
Relay Valve
12 to 24 VDC
Push-button switch
Internal circuit
SIG
+
–
Transmission
line
12 to 24 VDC
Relay
Indicator
Note: Do not short-circuit any out-
put
A terminal with the corre -
sponding B terminal, other-
wise the internal elements of
the
B7A will be damaged.
Ajj
Bjj
Bjj
Ajj
Bjj
Ajj
