1 Preparation
1-4 Name of each part
● Rear view
<BA75T/BA100T>
<BA100R>
A
B
C
D
I
H
F
E
A B C
D
E F
H
G
G
I
A: RS232C port
B: Contact signal port
C: Remote ON/OFF port
D: Input protection
E:
AC input terminal block
F: AC output terminal block
G: Input surge protection GND
H: Power supply output receptacles
(Backup is performed during power failure.)
I: Cooling fan (air vent)
A: Cooling fan (air vent)
B: RS232C port
C: Contact signal port
D: Remote ON/OFF port
E: Power supply output receptacles
(Backup is performed during power failure.)
F: Input protection
G:
AC input terminal block
H: AC output terminal block
I: Input surge protection GND
BA75T/BA100T/BA100R
19
1
