Omron BA75T - 9 References; Specifications

9 References
9-1 Specifications
9 References
9-1 Specifications
Model
BA75T
BA100T
BA100R
Method
Operation method
Full-time inverter supply method (Automatic Switching)
Cooling method
Forced air cooling
Input
Rated input voltage
100/110/115/120 VAC
Input voltage range
70±2 to 146±2 V AC (with less than 90% connection load)
80±2 to 146±2 V AC (with 90% or more connection load)
Frequency
Synchronous mode
50/60 Hz±5.5 Hz
Asynchronous mode
39 Hz to 71 Hz
Input Maximum current *1
9.6A
13A
Phase
Single-phase, two-wire (grounded)
Input protection
Non Fuse Breaker (10A)
Non Fuse Breaker (15A)
AC input terminal
Terminal block
Output
Rated output capacity
750 VA/600 W
1000 VA/800 W
Voltage
Commercial
operation
100V mode: 100VAC±2%, 110V mode: 110VAC±2%
115V mode: 115VAC±2%, 120V mode: 120VAC±2%
Backup operation
100V mode: 100VAC
±
2%, 110V mode: 110VAC
±
2%
115V mode: 115VAC±2%, 120V mode: 120VAC±2%
Frequency
Synchronous mode
Commercial operation: Synchronized with input frequency
Backup operation: 50/60 Hz±0.1 Hz
Frequency selection: Automatic selection when UPS start
Asynchronous mode
Commercial operation: 50/60 Hz±0.5%
Backup operation: 50/60 Hz±0.5%
Waveform
Commercial operation
Sine wave
Backup operation
Sine wave
Distortion rate
6% max. (Rectified load, at rated output)
3% max. (Resistance load, at rated output)
Phase
Single-phase, two-wire (grounded)
Output receptacle NEMA 5-15R x 4 / Terminal block
Battery
Type
Sealed lead battery
Voltage / Capacity x Quantity
12 V / 9 Ah x 2
Backup time (25°C, initial characteristics)
6 min. or more (525W)
5 min. or more (700W)
Charging time
8 hours
Battery life
Ambient temperature 25°C
Expected life: 5 years
Envi-
ron-
ment
Operating environment temperature/ humidity
0 °C to 40 °C, 25 to 85%RH with no condensation
Storage temperature
-15 °C to 40 °C, 10 to 90%RH with no condensation
Safety standard / RoHS directive compliance
UL1778 / RoHS compliant / CE
Disturbance voltage /
Radiated interference field strength
VCCI Class A
Internal power consumption (normal/maximum)
150W (*2) / 300W (*3)
Noise
50 dB
Dimensions (W x D x H)
128 mm x 345 mm x 215 mm
438 mm x 315 mm x 85 mm
Weight of unit
Approx. 12.5 kg
Approx. 12.5 kg
Approx. 13 kg
*1: Minimum input voltage 70V for 100V mode with 90% load
*2: Rated load/ Rated input voltage/ When fully charged
*3: Rated load/ Rated input voltage/ When battery charge current is at maximum
Note: About ECO mode, see p. 39.
BA75T/BA100T/BA100R
95
9
