Omron CJ1G/H-CPU series User Manual

249
Wiring Section 5-3
CJ-series 64-point Basic I/O Units (32 inputs, 32 outputs)
Connecting Cable
XW2Z-@@@K
Connector-Terminal Block Conversion Unit
XW2B-40G4
XW2B-40G5
XW2D-40G6
XW2D-40G6-RM
Output
Input
Connector-Terminal Block Conversion Unit
XW2B-40G4
XW2B-40G5
XW2D-40G6
Note: Two sets of an XW2Z-@@@N Connecting Cable
and an XW2C-20G5-IN16 or XW2C-20G6-IO16
Connector-Terminal Block Conversion Unit can
also be used.
Note: Two sets of an XW2Z-@@@N Connecting Cable and
an XW2C-20G6-IO16 Connector-Terminal Block
Conversion Unit can also be used.
CJ1W-MD263 (Mixed I/O Units, MIL connectors, 24-V DC
inputs/transistor outputs)
CJ1W-MD563 (Mixed I/O Units, MIL connectors, TTL inputs/TTL
outputs)
CJ-series 32-point Basic I/O Units (16 inputs, 16 outputs)
Connecting Cable
G79-O
@@C
Output
Input
Connector-Terminal Block Conversion Unit
XW2B-20G4
XW2B-20G5
XW2D-20G6
CJ1W-MD232 (Mixed I/O Units, MIL connectors, 24-V DC
inputs/transistor outputs)
CJ1W-MD233 (Mixed I/O Units, MIL connectors, 24-V DC
inputs/transistor outputs)
