Omron CJ1M-CPU22 User Manual

117
ORIGIN SEARCH: ORG(889) Section 5-9
Operands P: Port Specifier
The port specifier specifies the port where the pulses will be output.
C: Control Data
The value of C determines the origin search method.
Operand Specifications
PPort
0000 hex Pulse output 0
0001 hex Pulse output 1
03478 111215
C
Always 0 hex.
Always 0 hex.
Pulse output method (See note.)
0 hex: CW/CCW
1 hex: Pulse + direction
Mode
0 hex: Origin search
1 hex: Origin return
Note: Use the same pulse output method when using both pulse outputs 0 and 1.
Area P C
CIO Area --- ---
Work Area --- ---
Holding Bit Area --- ---
Auxiliary Bit Area --- ---
Timer Area --- ---
Counter Area --- ---
DM Area --- ---
EM Area without bank --- ---
EM Area with bank --- ---
Indirect DM/EM
addresses in binary
--- ---
Indirect DM/EM
addresses in BCD
--- ---
Constants See description of operand. See description of operand.
Data Registers --- ---
Index Registers --- ---
Indirect addressing
using Index Registers
--- ---
