Omron CJ1M-CPU22

55
PLC Setup Settings Section 4-2
High-speed Counter 1 Circular Max. Count (Ring Counter Maximum Value)
High-speed Counter 1 Reset Method
High-speed Counter 1 Pulse Input Setting (Pulse Input Mode)
Note When the CX-Programmer is being used to make the setting, the setting is
input in decimal.
Programming
Console setting
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
54 00 to 15 00000000 to
FFFFFFFF hex
(See note.)
00000000
hex
Sets the max. ring count for high-
speed counter 1.
When the high-speed counter 1
counting mode is set to ring mode,
the count will be reset to 0 automati-
cally when the counter PV exceeds
the max. ring count.
A272
(Rightmost 4
digits of the
high-speed
counter 1
PV)
When operation
starts
55 00 to 15 A273
(Leftmost 4
digits of the
high-speed
counter 1
PV)
Programming
Console setting
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
53 04 to 07 0 hex: Z phase,
software reset
(stop comparing)
1 hex: Software
reset (stop com-
paring)
2 hex: Z phase,
software reset
(continue com-
paring)
3 hex: Software
reset (continue
comparing)
0 hex Specifies the reset method for high-
speed counter 1.
--- When power is
turned ON
Programming
Console setting
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
53 00 to 03 0 hex: Differential
phase inputs
1 hex: Pulse +
direction inputs
2 hex: Up/Down
inputs
3 hex: Increment
pulse input
0 hex Specifies the pulse-input method for
high-speed counter 1.
--- When power is
turned ON
