Omron CJ1M-CPU22

63
PLC Setup Settings Section 4-2
Pulse Output 1 Origin Detection Method
Pulse Output 1 Origin Search Operation Setting
Pulse Output 1 Origin Search Operating Mode
Pulse Output 1 Undefine Origin Setting (CJ1M CPU Unit Ver. 2.0 Only)
Pulse Output 1 Origin Input Signal Type
Programming
Console setting
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
275 08 to 11 0 hex: Method 0
(Origin detection
method 0)
1 hex: Method 1
(Origin detection
method 1)
2 hex: Method 2
(Origin detection
method 2)
0 hex Specifies the origin detection method
for pulse output 1.
--- When operation
starts
Programming
Console setting
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
275 04 to 07 0 hex:
Inverse 1 (Rever-
sal mode 1)
1 hex:
Inverse 2 (Rever-
sal mode 2)
0 hex Specifies the origin search operation
for pulse output 1.
--- When operation
starts
Programming
Console setting
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
275 00 to 03 0 hex: Mode 0
1 hex: Mode 1
2 hex: Mode 2
0 hex Specifies the origin search mode for
pulse output 1.
--- When operation
starts
Programming
Console setting
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
286 12 to 15 0 hex: Hold
1 hex: Undefine
0 hex Specifies whether to hold the origin
setting when the CW/CCW limit input
signal is input during execution of an
origin search or pulse output function.
--- When operation
starts
Programming
Console setting
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
286 08 to 11 0 hex: NC
1 hex: NO
0 hex Specifies whether the Origin Input
Signal for pulse output 1 is normally
closed or normally open.
--- When operation
starts
