130
Built-in Inputs Section 6-1
Bit Allocations
Code Word
address
Bit Pulse input mode
Differential phase Pulse + direction Up/down input Increment
IN6 CIO 2960 06 High-speed counter
1 Phase A
High-speed counter
1 Count input
High-speed counter
1 Increment input
High-speed counter
1 Count input
IN7 07 High-speed counter
1 Phase B
High-speed counter
1 Direction input
High-speed counter
1 Decrement input
---
IN2 02 High-speed counter
1 Phase Z
High-speed counter
1 Reset input
High-speed counter
1 Reset input
High-speed counter
1 Reset input
IN8 08 High-speed counter
0 Phase A
High-speed counter
0 Count input
High-speed counter
0 Increment input
High-speed counter
0 Count input
IN9 09 High-speed counter
0 Phase B
High-speed counter
0 Direction input
High-speed counter
0 Decrement input
---
IN3 03 High-speed counter
0 Phase Z
High-speed counter
0 Reset input
High-speed counter
0 Reset input
High-speed counter
0 Reset input
